Wave three-dimensional acoustic tiles create a calm flowing design across its surface.

Installed using adhesive-free clips, these tiles can be configured with a horizontal or vertical wave and mixed with different colourways to create a uniquely textural installation. The tiles design, depth and material combine to offer high acoustic performance, ideal for controlled reverberated noise that's conducive to workplace productivity and acoustic comfort in hospitality settings.

Colourways

Wave Tile 908 Cream

908

Wave Tile 101 Frost

101

Wave Tile 447 Slate

447

Wave Tile 269 Wine

269

Wave Tile 487 Blush

487

Wave Tile 542 Black

542

Wave Tile 660 Coronet

660

Wave Tile 349 Vineyard

349

Product Specifications

Designer:

Bang Design in collaboration with Woven Image

Dimensions:

Length: 500mm (+/- 5mm), Width: 500mm (+/- 5mm), Depth: 50mm (+/- 5mm), Thickness: 4mm (+/- 0.5mm)

Composition:

100% PET (27% recycled)

Fire Test Result:

AS 3837: Group 3
ASTM E84 Unadhered: Class 1 or A
BS 476: Class 2Y

Sound Absorption Test Method:

AS ISO 354: 2006 (R2016)

Weighted Alpha Coefficient (αw):

Direct fix: 0.50 (MH)

Sound Absorption Average (SAA):

Direct fix: 0.58

Noise Reduction Coefficient (NRC):

Direct fix: 0.60

Sound Absorption Class:

D (Direct fix)

Hardware Image for Website_3D Tile Clips.jpg

Sustainability

Global GreenTag™ GreenRATE Level A

A third-party certification that assesses products’ ingredients, supply chain and manufacture for environmental, social and Building Code compliance. GreenRate Level A is a recognised initiative for Green Star Responsible Products credits.

Low VOC Emissions

Products with low volatile organic compounds (VOCs) are less harmful to the environment and human health and contribute to good Indoor Air Quality (IAQ).
