Pendent Splay
Pendent Splay's design features penta shapes cut out in irregular spacing that increase from the middle of the panel to the edges.
These hanging acoustic panels help to create zones and provide privacy, without blocking sightlines in open plan offices or hospitality settings. Pendents are supplied with a beautifully engineered suspension kit that enable them to be secured to the floor, if desired. Kits include ceiling mounts, cables, wire spacers, and brackets with refined sleeves in three finishes. EchoPanel® is a superior upcycled product with a 10-year life expectancy, after which the material is 100% recyclable. The Pendent collection is made with EchoPanel®, that achieves numerous environmental certifications recognised by International Green Building Tools, including WELL™, LEED®, GreenStar® and BREEAM®.
Colourways
500
454
908
468
721
402
580
101
487
495
484
193
269
447
444
442
274
106
124
295
167
573
338
330
551
633
381
579
349
384
542
550
660
365
Product Specifications
Designer:
Bang Design in collaboration with Woven Image
Dimensions:
Height: 2400mm (+/- 5mm), Width: 1200mm (+/- 10mm), Thickness: 12mm (+/- 7%). Also available in 24mm (+/-7%), specifications will differ.
Composition:
100% PET (80% post-consumer recycled)
Fire Test Result:
AS 1530.3
BS EN 13501.1: Classification B - s1, d2
GB 8624 B1
ISO 9705: Group 1
ASTM E84 Unadhered: Class 1 or A
BS EN 45545-2 + A1 Annex C: CIT: 0.05
Sound Absorption Test Method:
AS ISO 354: 2006 (R2016)
Weighted Alpha Coefficient (αw):
EchoPanel® 12mm achieves direct fix: 0.30 (MH), 20mm air gap: 0.45 (MH), 50mm air gap: 0.60 (MH)
Sound Absorption Average (SAA):
EchoPanel® 12mm achieves direct fix: 0.43, 20mm air gap: 0.61, 50mm air gap: 0.75
Noise Reduction Coefficient (NRC):
EchoPanel® 12mm achieves direct fix: 0.45, 20mm air gap: 0.60, 50mm air gap: 0.75
Sound Absorption Class:
D (Direct fix)
D (20mm air gap)
C (50mm air gap)
Additional Acoustic Information:
Sound Absorption Class result is based on EchoPanel® 12mm. Acoustic results will vary by pendent design. MH = Mid to High Frequency
Sustainability
Low VOC Emissions
Products with low volatile organic compounds (VOCs) are less harmful to the environment and human health and contribute to good Indoor Air Quality (IAQ).
